Essential details
- Warranty:
3years
- Anode Material:
LFP
- Chargeable:
Yes
- Application:
Golf Carts
- Battery Size:
32700
- Brand Name:
YIT
- Certification:
ISO9001,CNAS,CE,ROHS,FCC,MSDS,UN38.3,IEC,BIS,CB
- Model Number:
YIT-LF4070 12V 42Ah
- Place of Origin:
Guangdong, China
- Weight:
Approx. 4.8Kg
- Nominal Voltage:
12.8V
- Nominal Capacity:
42Ah
- Energy:
537.6Wh
- Internal Resistance:
≤50mΩ
- Cycle Life:
2000 Cycles
- Max.Charging Voltage:
14.0~14.6V
- Water Dust Resistance:
IP55
- Casing:
Plastic
- Dimension(L*W*H*TH):
223*121*175*175mm
- Terminal:
M6
Supply Ability
- Supply Ability
- 100000 Piece/Pieces per Month
Packaging & delivery
- Packaging Details
1. We usually use the carton for packing.
2.As customer requirements packing.
- Port
Shenzhen/HK
- Lead time:
| Quantity(pieces) | 1 - 500 | >500 |
| Lead time (days) | 7 | To be negotiated |
Electrical Characteristics | Nominal Voltage | 12.8V |
Nominal Capacity | 42Ah@0.2C |
Energy | 537.6Wh |
Internal Resistance | ≤50mΩ |
Cycle Life | 2000 Cycles @ 0.2C Charging/Discharging ,Until 70% Capacity |
Self Discharge | ≤3.5% per month at 25℃ |
Standard Charging | Max.Charging Voltage | 14.0~14.6V |
Charging Mode | At 0℃~45℃ temperature, charged to 14.6V at a constant current of 0.2C, and
then,changed continuously with constant voltage of 14.6V until the current was not
more than 0.02C |
Charging Current | 21A |
Max.Charging Current | 42A |
Standard Discharging | Discharging Current | 21A |
Max. Continuous Current | 50A |
Max.Pulse Current | 100A(<3S） |
Discharging Cut-off Voltage | 10.0 |
Operating Condition | Charge Temperature | 0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity |
Discharge Temperature | -20℃ to 60℃(-4℉ to 140℉) @60±25% Relative Humidity |
Storage Temperature | 0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity |
Water Dust Resistance | IP55 |
Structure | Cell & Format | IFR32700 N60,4S7P |
Casing | Plastic |
Dimension(L*W*H*TH) | 223*121*175*175 |
Weight | Approx. 4.8Kg |
Terminal | M6 |
Our Advantages
◆ Using the technology of lithium iron phosphate cell, superior safety,thousands of cycles, 100%DOD, under normal conditions.
◆Built-in automatic protection for over-charge, over discharge, over current and over temperature.
◆ Free of maintenance .
◆ Internal cell balancing.
◆ Lighter weight: About 40% ~50% of the weight of a comparable lead acid battery.
◆ Can be charged using most standard lead-acid charges (set).
◆ Wider temperature range:-20℃~60℃.
◆ Support for Series application expansion (up to 51.2V) and two in parallels.
